ESP-7K Electrostztic Precipitator

Description

The ElectroESP ESP-7K is a high-capacity electrostatic precipitator engineered for demanding commercial and industrial kitchen ventilation systems. Offering an airflow capacity of 6,000–7,500 m³/h and up to 95% filtration efficiency, it efficiently removes oil mist, smoke, grease, and fine airborne contaminants. Ideal for large commercial kitchens, hotels, catering facilities, food production plants, and high-capacity ventilation applications.

Specifications

Air Flow

6,000–7,500 m³/h

Filter Pressure Drop

100 + 50 Pa

Filtration Efficiency (0.3–5 μm)

95%

Input Voltage

220V / 50/60Hz

High Voltage Power Unit

14,000–7,000 HV-LV

Collection Surface

41.4 m²

Collector Cell Quantity

3

Ionization Wire Quantity

24

Max. Operating Temperature

65 °C

Automation Module

Optional

Pre Filter

Standard

Rear Filter

Optional

Oil Drain Tray

Standard

Origin

England / Turkey

Dimensions

Height (H)

575 mm

Width (W)

1450 mm

Length (L)

575 mm

Air Inlet / Outlet

430 × 1190 mm

Weight

105 kg
